| DONANIM ÖZELLİKLERİ | |
|---|---|
| Arabirim | • 5× 10/100 Mbps RJ45 Ports (4× 10/100 Mbps 802.3af PoE Ports) • AUTO Negotiation • AUTO MDI/MDIX |
| Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Sayısı | Fanless |
| Kurulum | • Desktop • Wall Mounting |
| Güç Kaynağı | External Power Adapter (Output: 53.5VDC / 0.81A) |
| PoE Portları (RJ45) | • Standard: 802.3 af compliant • PoE Ports: Ports 1–4, up to 15.4 W PoE output per port • Power Supply: 41 W |
| LED Göstergesi | • Power • Link/Act • PoE Status • PoE MAX |
| Boyutlar ( W X D X H ) | 3.9×3.9×1.0 in (100×98×25 mm) |
| Maks. Güç Tüketimi | • 2.40 W (220 V/50 Hz no PD connected) • 46.45 W (220 V/50 Hz with 41 W PD connected) |
| Max Heat Dissipation | • 8.15 BTU/h (220 V/50 Hz no PD connected) • 157.93 BTU/h (220 V/50 Hz with 41 W PD connected) |
| PERFORMANS | |
|---|---|
| Anahtarlama Kapasitesi | 1 Gbps |
| Paket Yönlendirme Hızı | 0.744 Mpps |
| MAC Adres Tablosu | 2K |
| Jumbo Frame | 2 KB |
| YAZILIM ÖZELLİKLERİ | |
|---|---|
| Gelişmiş Özellikler | • Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data transmission) • PoE Auto Recovery Button (Ports 1-4) • Compatible With IEEE 802.3af Compliant PDs • Mac Address Auto-Learning and Auto-Aging • IEEE 802.3x Flow Control • Green Technology |
| Transfer Metodu | Store and Forward |
| DİĞERLERİ | |
|---|---|
| Sertifika | CE, FCC, RoHS |
| Paket İçeriği | • LS105LP • Power Adapter • Installation Guide |
| Ortam | • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
| PoE Desteği | 4 Adet |
| Port Sayısı | 5 Adet |
| Rack Kasa | Uyumlu Değil |
| SFP Yuva | Yok |
| Veri Transfer Hızı | 100Mbps |
| Yönetim | Yönetilemez |
