genel bakış
| INTEL H510 | ||
|---|---|---|
| CPU Support | Support 11th/10th generation Comet Lake-S Corei9/Corei7/Corei5/Corei3/Pentium/Celeron series processors for LGA 1200 socket | |
| Chipset | Intel H510 Chipset | |
| On-Board Graphics | Integrated Graphics Processor-Intel® HD Graphics support | |
| Memory | Dual Channel DDR4 2133/2400/2800/3000/3200MHz Support XMP overclock | |
| DIMM | 2 x Memory Slots | |
| LAN | Realtek 100/1000 Mbps Gigabit LAN onboard | |
| Audio | 3.5mm Port, 5.1 Channel, LED Audio Support | |
| Real I/O | 1 x PS/2 mouse port 1 x PS/2 keyboard port 1 x DP port 1 x HDMI port 2 x USB 2.0 port 2 x USB 3.0 port 1 x RJ45 3 x Audio jack | |
| Internal I/O | 3x USB connector, can support 4*USB 2.0 & 2*USB 3.0 | |
| SATA | 3 X SATA3.0 6Gb/s M.2 (PCI-E 3.0 X4 NVME SSD | |
| Form Factor | Micro-ATX (22cm X 17 cm) | |
| Expansion Slots | 1 x PCI Express x16 slot 1 *PCI Express x1 slot | |
| OS Support | Support Windows 7 / 8 / 8.1 / 10 / 11 (x64) | |
| Mounting | 6 mounting holes | |
| Accessories | 1 x SATA cable 1 x I/O Backboard 1 x User Manual 1 x Driver CD | |
| Remark | All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. PCB color and bundled software versions are subject to change without notice. Brand and product names mentioned are trademarks of their respective companies. |
| Chipset | INTEL H510 |
| CPU Platformu | INTEL |
| CPU Yuva Yapısı | 1200 PIN |
| Display Port (DP) | VAR |
| HDMI | VAR |
| Kablosuz Bluetooth | YOK |
| Kablosuz Wi-Fi | YOK |
| Kasa Uyumu | Micro ATX |
| RAM Desteği | DDR4 |
| RAM Yuva Adeti | 2 ADET |
| Type-C | YOK |
